SAE series is integrated cross zero transfer technology (which makes the relays swithing on/off across the zero point ,it reduces the shock to the relays and to the loads at the switching point ,so that you can get a more smooth output and expand the lifespan of relays )
Features:
1,Well-selected reliable components
2,Heavy-duty transformer
3,IC controlled circuit
4,Full protection design
5,Delay function integrated
|
MODEL |
SAE-500VA |
SAE-1000VA |
SAE-1500VA |
SAE-2000VA |
||
|
POWER |
500VA |
1000VA |
1500VA |
2000VA |
||
|
TECHNOLOGY |
Meter /digital display+relay control+toroidal transformer |
|||||
|
DELAY TIME |
Short delay: 7 sec Long delay: 3-7min (customized) |
|||||
|
INPUT |
INPUT RANGE |
110-270V/90-280V(customized) |
||||
|
INPUT FREQUENCY |
50/60HZ |
|||||
|
OUTPUT |
OUTPUT VOLTAGE |
AC220/110V |
||||
|
OUTPUT ACCURACY |
7%(customized) |
|||||
|
CONNECTOR |
socket |
socket |
socket |
socket |
||
|
PHASE |
Single phase |
|||||
|
METER DISPLAY STATUS |
Input voltage /output voltage |
|||||
|
PROTECTION |
Over voltage protection 248V+-2V |
|||||
|
Over load protection |
||||||
|
High temperature protection |
||||||
|
Circuit protection (with fuse or circuit breaker) |
||||||
|
ENVIROMENTAL |
OPERATING TEMPERATURE |
0-40°C |
||||
|
STORAGE TEMPERATURE |
-10-40°C |
|||||
|
OPERATING RELATIVE HUMIDITY |
10%RH-102%RH:non condensing |
|||||
|
PHYSICAL |
PCS/CARTON |
6 |
6 |
6 |
6 |
|
|
PACKING SIZE(CM) |
58.5*35*50 |
58.5*35*50 |
58.5*35*50 |
58.5*35*50 |
||
|
G.W.(KGS) |
18 |
26 |
26 |
26 |
||
|
RELAY |
4/5 |
4/5 |
4/5 |
|
||
|
QTY/20FT |
283 |
283 |
283 |
283 |
||
|
PACKAGE |
Plastic bag + color box + master carton |
|||||
