The advantages of this model:
•Suitable for wall mounting •Stepless voltage regulation over a wide range •The high output voltage accuracy (1.5%) •Surge protection •Protection against short circuit and overheating •Differentiation and fault indication •Informative LCD-display •Modern design •urge protection up to 300 V •Microprocessor control •High speed regulation •The wide input voltage range •The multistage defense
|
Model |
SDWII-4000-L |
SDWII-6000-L |
SDWII-10000-L |
SDWII-12000-L |
|
Nominal Power |
4000VA |
6000VA |
10000VA |
12000VA |
|
Power Factor |
0.6-1.0 |
|||
|
Input |
||||
|
Operating Voltage Range |
120~275V |
|||
|
Regulation Voltage Range |
140~260V (custom made) |
|||
|
Frequency |
50HZ |
|||
|
Connection Type |
Input terminal block |
|||
|
Output |
||||
|
Operating Voltage |
180~255V |
|||
|
High Cut Voltage |
255V |
|||
|
Low Cut Voltage |
180V |
|||
|
Safety Cycle |
8 Seconds / 180 Seconds (Optional) |
|||
|
Frequency |
50HZ |
|||
|
Connection Type |
Output terminal block |
|||
|
Regulation |
||||
|
Regulation % |
1.5% / 3.5% |
|||
|
Number of Taps |
NO |
|||
|
Transformer Type |
Toroidal auto transformer |
|||
|
Regulation Type |
Servo type |
|||
|
Indicators |
||||
|
LCD Display |
Input voltage Output voltage Delay time Load usage Normal working Temperature of transformer Error code |
|||
|
Protection |
||||
|
Over Temperature |
Auto Shutdown at 120 ℃ |
|||
|
Short Circuit |
Auto Shutdown |
|||
|
Overload |
Auto Shutdown |
|||
|
Over / Under Voltage |
Auto Shutdown |
|||
Packaging information :
|
|
